How to Use the Brim API

Brim offers a powerful REST API that allows you to automate chart abstraction tasks, streamline your research workflows, and integrate Brim into your existing data infrastructure.

This guide provides an overview of how to get started, what you can do with the API, and how to authenticate securely.

Why Use the Brim API?

You might use the API to:

• Create and update patients in bulk
• Run automated abstraction workflows
• Retrieve structured data outputs
• Integrate Brim with systems like REDCap or clinical databases
• Monitor abstraction progress programmatically

Getting Access

To use the API, you need an API Token. You'll find instructions for creating one here.

Brim uses bearer token authentication. Include your token in the header of each API request like this:

Authorization: Bearer YOUR_TOKEN_HERE

What You Can Do With the API

Upload Data & Resources

• Upload new or updated patient notes as a CSV.
• Upload new or updated resource or reference documents that can be used to create or optimize variables.

Run Generation Automatically

• Generate labels for some or all patients and variables

Coming Soon: Export Generated Labels

Example Script

Below is an example python script for how to use the various endpoints.

#!/usr/bin/env python3
import argparse
import os
import sys
from pathlib import Path

import requests


def upload_csv(filepath, project_id, api_token, api_url, generate_after_upload):
    """
    Upload a CSV file to the API endpoint.

    Args:
        filepath (str): Path to the CSV file to upload
        project_id (int): Project ID to upload to
        api_token (str): API project token for authentication
        api_url (str): Base URL of the API
        generate_after_upload (bool): Start generation after upload.

    Returns:
        bool: True if successful, False otherwise
    """
    if not os.path.exists(filepath):
        print(f"Error: File not found: {filepath}")
        return False

    try:
        # Prepare headers with Bearer token
        headers = {
            "Authorization": f"Bearer {api_token}",
        }

        # Prepare the multipart form data
        files = {"csv_file": open(filepath, "rb")}
        data = {
            "project_id": str(project_id),
            "generate_after_upload": generate_after_upload,
        }

        # Make the request
        endpoint = f"{api_url.rstrip('/')}/api/v1/upload/csv/"
        response = requests.post(endpoint, headers=headers, data=data, files=files)

        # Check response
        if response.status_code == 200:
            result = response.json()
            print(f"Success! Upload successful: {result['data']['original_filename']}")
            print(f"API Session ID: {result['data']['api_session_id']}")
            return True
        else:
            print(f"Error: Upload failed with status code {response.status_code}")
            print(f"Response: {response.text}")
            return False

    except requests.exceptions.RequestException as e:
        print(f"Error: Failed to connect to server: {e}")
        return False
    except Exception as e:
        print(f"Error: {str(e)}")
        return False
    finally:
        # Ensure file is closed
        if "files" in locals():
            files["csv_file"].close()


def main():
    parser = argparse.ArgumentParser(description="Upload a CSV file to the API")
    parser.add_argument("filepath", type=str, help="Path to the CSV file to upload")
    parser.add_argument(
        "--project-id",
        type=int,
        help="Project ID to upload to",
        default=os.environ.get("PROJECT_ID"),
    )
    parser.add_argument(
        "--api-token",
        type=str,
        help="API token for Bearer authentication",
        default=os.environ.get("API_TOKEN"),
    )
    parser.add_argument(
        "--api-url",
        type=str,
        help="Base URL of the API",
        default=os.environ.get("API_URL", "http://localhost:8000"),
    )
    parser.add_argument(
        "--generate-after-upload",
        type=bool,
        help="Start generation after upload completes",
        default=False,
    )

    args = parser.parse_args()

    # Validate required arguments
    if not args.project_id:
        print(
            "Error: Project ID is required. "
            "Provide it via --project-id or set PROJECT_ID "
            "environment variable"
        )
        sys.exit(1)

    if not args.api_token:
        print(
            "Error: API token is required. "
            "Provide it via --api-token or set API_TOKEN "
            "environment variable"
        )
        sys.exit(1)

    # Normalize filepath
    filepath = str(Path(args.filepath).expanduser().resolve())

    # Attempt upload
    success = upload_csv(
        filepath,
        args.project_id,
        args.api_token,
        args.api_url,
        args.generate_after_upload,
    )
    sys.exit(0 if success else 1)


if __name__ == "__main__":
    main()

Try It Out

You can explore and test all available endpoints at:

👉 https://demo.brimanalytics.com/api/docs#/

This interactive interface lets you try the API with your token and see example responses.

Need Help?

If you run into issues or have a question about what’s possible via the API, reach out to our team any time by emailing support@brimanalytics.com.
